Cast Plate

MetalLearn® – Aluminum Products Sheet Alloys – Cast Tool and Die Plate Cast Plate



Features:

  • Exceptional Stability
  • Little distortion after machining
  • Excellent machined surface finish of 25 Ra or RMS*
  • Close thickness tolerances, +/- .005”

Trade Names:

  • Mic 6
  • M-1, M-5
  • ATP-5

*Ra and RMS, expressed in micro-inches, measure the average height of grooves on the surface of a plate.
